Specifications:
- Stator Diameter: 42 mm (1.65 in)
- Stator Thickness: 25 mm (0.98 in)
- No. of Stator Arms: 12
- No. of Stator Poles: 10
- Motor Wire: 1-Strand 1.6 mm
- Motor Kv : 810KV RPM/Volt
- No-Load Current (Io/10V): 3.6 Amps
- Motor Resistance (RM): 0.009 Ohms
- Max Continuous Current: 115 Amps
- Max Continuous Power: 3404 Watts
- Weight : 393 Grams (13.77 oz)
- Outside Diameter: 52.3 mm (2.06 in)
- Shaft Diameter: 5.98 mm (0.24 in)
- Body Length: 51.50 mm (2.03 in)
- Overall Shaft Length: 85.5 mm
- Max Lipo Cell: 8s
- Max Peak Current: 170 Amps (5 seconds)
- Max Peak Power: 5032 Watts (5 seconds)
- Motor Timing: 5deg
- Drive Frequency: 8kHz
