Descripción
Benefits at a glance
- automatic activation and deactivation, depending on the operational status of the model (motor switch position, stick inputs)
- all voltages can be monitored separately via telemetry
- charging currents are adjustable, both for initial charging and for topping-up during operation
- recharges automatically and immediately whenever needed
- companion App warns the pilot whenever the backup is used
- this unit ensures the everyday operation of your valuable models
Hardware features
- wide input voltage range from 3 V up to 12.6 V (3s LiPo) with a 16 V peak margin
- Capacity 3 x 110 F, 40+ A peak current
- short circuit protection
- fast charge (adjustable) up to 2.4 A
- charging current is ramped up slowly, to protect main power supply
- decoupled channels for power delivery and for charging
- VLink Telemetry monitoring and control
- no r/c channel (servo connector) must be sacrificed, pass-through via main connector
- active balancer between capacitors for low idle discharge
- up to 3 units can be connected parallel, tripling the capacity and power; cascaded units are fully suported by companion App
- telemetry input for other sensors or ESCs (daisy-chaining)
